TPC Advance

Advance 750 Piezo Scaler



Standard Scaler Features:

  • Compact unit housing for easy placement anywhere in the operatory
  • Extremely gentle on the patient, causes little or no sensitivity
  • No heat built up in handpiece tip with the extended use
  • Autoclavable handpiece
  • Extensive power range to allow the widest choice of clinical applications
  • Fine water spray eliminates excessive overspray onto the patient
  • Thin subgingival tips are available
  • 5 Tips included with the unit
  • Intense LED light source in Model A750-LED
  • 1-year warranty (tips excluded)

Technical Data:

  • Absorbed Power: Max 15W
  • Scaler: Max 10W, 24-28kHz, automatic tuning
  • Water Pressure: 30 - 145 PSI
  • Water Consumption: 10-50 cc/min
  • Approvals: ETL, according to UL – 2601 – 1
  • Classification according to Medical Device
  • Directive 93/42 EEC: Class 11a

Specifications:

  • Input rating: 115/230V, 50/60 Hz
  • Dimensions: 4.6" x 6.1" x 2.8"
  • Weight: 4.7 lbs
  • Frequency: 32 kHz
  • Water pressure: 1-4 kg/cm²
  • Fuses: 230V, 2 per unit; F0.5A 250V-CQ-S500
  • Fuses: 110V, 1 per unit; F1A 250V-CQ-S500
